§3944. Guard Clearances.


(a) Where a guard or enclosure is within 2 inches of moving parts, openings through the guard shall be of such size as will preclude the passage of any object one-half inch in diameter.

(b) Where a guard or enclosure is within 4 inches of moving parts, openings through the guard shall be of such size as will preclude the passage of any object greater than one-half inch in diameter.

(c) Where a guard is located between 4 inches and 15 inches from moving parts, the maximum opening shall be of such size as will preclude the passage of any object greater than 2 inches in diameter. Where a slatted guard is used, the width of the opening shall be not greater than 1-inch.

(d) Standard railing guards shall be placed not less than 15 inches nor more than 20 inches from any moving parts provided; however, that where clearances from other moving parts are less than 15 inches, such parts shall be guarded as required elsewhere in these orders.

(e) The use of nylon mesh or materials of equivalent strength with holes not exceeding 1/2-inch to modify an existing substandard fan guard is acceptable, provided the combination of the two provides adequate protection and the mesh cannot be pushed into the danger zone during normal use.

Table G-1
GUARD MATERIALS



Material

A
Clearance from moving part at all points

(See Fig G-2)

Inches

B
Largest mesh or opening allowable

(See Fig G-1)

Inches

C
Minimum gauge (US Standard) or thickness



Gauge/Inches

Woven wire Under 2 3/8 No 16
2-4 No 16
4-15 2 No 12
Expanded metal Under 4 No 18
4-15 2 No 13
Perforated metal Under 4 No 20
4-15 2 No 14
Sheet metal Under 4   No 22
4-15   No 22
Plastic Under 4 *
4-15 2 *
Plywood or equivalent Under 4   5/16
Plywood or equivalent 4-15   5/16
Solid wood Under 4   1
Solid wood 4-15   1
Wood or metal strip crossed Under 4 3/8 Metal No 16
  Wood 3/4
4-15 2 Metal No 16
  Wood 3/4
Wood or metal strip not crossed Under 4 Metal No 16
   Wood 3/4
4-15 1 Metal No 16
   Wood 3/4
Standard rail Min 15
Max 20
Other materials that meet the strength requirements of this table and provide equivalent protection may be used
* Tensile strength of 10,000 lb/in2

Table G-1



Image 2 (5.25" X 7") Not available for Offline Print to STP or FAX




Image 3 (8.5" X 6.25") Not available for Offline Print to STP or FAX




Image 4 (5.75" X 7") Not available for Offline Print to STP or FAX



Image 5 (4.75" X 7") Not available for Offline Print to STP or FAX




Image 6 (8.5" X 6") Not available for Offline Print to STP or FAX



Image 7 (3.75" X 7") Not available for Offline Print to STP or FAX




Image 8 (3.25" X 7") Not available for Offline Print to STP or FAX



    Note: Authority cited: Section 142.3, Labor Code. Reference: Section 142.3, Labor Code.
